CL/HB 11-13PRIMEFP Single Wall Spec Sheet

Click or Scan – 3D viewer

MODELOUTSIDE DIMENSIONS (O.D.)
Width (W) x Depth (D) x Height (H)		INSIDE DIMENSIONS (I.D.)
Width (W) x Depth (D) x Height (H)		FLOOR AREAWEIGHT
CL-11PRIMEFP74'4" x 3'5" x 7'9"
1321mm x 1041mm x 2362mm		3'8" x 2'9" x 6'6"
1118mm x 838mm x 1981mm		14 sq. ft.
1.3sq. m.		1,518 lbs
689 kg
CL-11APRIMEFP74'4" x 4'4" x 7'9"
1321mm x 1321mm x 2362mm		3'8" x 3'8" x 6'6"
1118mm x 1118mm x 1981mm		18.75 sq. ft.
1.74 sq. m.		1,754 lbs
796 kg
CL-12PRIMEFP75'3" x 4'4" x 7'9"
1600mm x 1321mm x 2362mm		4'7" x 3'8" x 6'6"
1397mm x 1118mm x 1981mm		22.73 sq. ft.
2.11 sq. m.		1,993 lbs
904 kg
CL-12BPRIMEFP76'2" x 4'4" x 7'9"
1880mm x 1321mm x 2362mm		5'6" x 3'8" x 6'6"
1676mm x 1118mm x 1981mm		26.72 sq. ft.
2.48 sq. m.		2,229 lbs
1,011 kg
CL-13PRIMEFP76'2" x 5'3" x 7'9"
1880mm x 1600mm x 2362mm		5'6" x 4'7" x 6'6"
1676mm x 1397mm x 1981mm		32.38 sq. ft.
3.01 sq. m.		2,515 lbs
1,141 kg
CL-13APRIMEFP76'2" x 6'2" x 7'9"
1880mm x 1880mm x 2362mm		5'6" x 5'6" x 6'6"
1676mm x 1676mm x 1981mm		42.25 sq. ft.
3.93 sq. m.		2,776 lbs
1259 kg

CL/HB 11-13PRIMEFP-Series Audiometric Rooms features a 7″ (178mm) Total Rise Isolated Floor.CL/HB 11-13PRIMEFP Rooms are ideal for hospitals and busy clinics with high noise, high traffic areas. The CL/HB 11-13PRIMEFP come standard with:

  • 36” (914mm) W X 73 3/4” (1873mm) H Door (11 And 11a Rooms – 32”W X 73 3/4”H)
  • 24″ W x 30″ H (610mm x 762mm) Window
  • Plug And Play Electrical
  • LED Lighting
  • Jack Panel Complete With 12 1/4” Phone Jacks, 2 Usb, And A 1” (25mm) Pass-Through

Optional Features

  • 20” X 60” (508mm X 1524mm) Window in Door
  • Sprinkler Access Hole
  • HVAC Collars (1 Set, Includes Internal Utility Box For Thermostat By Others)
  • Additional Duplex Outlets
